NoStrandAMust - Bodenkontaktsimulation zur Verbesserung der Lokomotionsperformance mobiler Roboter

NoStrandAMust - Bodenkontaktsimulation zur Verbesserung der Lokomotionsperformance mobiler Roboter

  • Duration:

NoStrandAMust is a project with the goal of experimentally investigating the ground interaction of different robots and generating models for the interaction using AI methods. These models are to be used and verified in simulation and to improve the autonomy of the robots. On the one hand, the models will be used for motion planning and thus increase the efficiency and safety of the systems. On the other hand, the models will be used to analyze the current ground conditions at runtime and thus prevent the systems from maneuvering into dangerous areas. Thus, the methods, models and simulations to be developed in NoStrandAMust increase the autonomy, safety and efficiency of mobile robot systems. The methods to be developed are thus seen as an essential contribution to the success of future missions.

In order to achieve the overall goal of the joint project, the autonomy of robotic systems by ground interaction models, four essential contributions are made in NoStrandAMust four essential contributions are made:

  1. Big-data collection of performance data of different mobile systems under different environmental conditions - Different systems here refers to different locomotion modes, propulsion systems, weight classes, and contact geometries and materials. Data will be collected from six walking systems with different morphologies and foot designs, as well as data from different wheel-driven concepts, each of which will be tested on four different surfaces under circumstances with different locomotion behaviors.
  2. Generation of soil interaction models using AI methods - state-of-the-art regression and classification methods as well as other machine learning methods are required for the generation of soil interaction models. In particular, preliminary work with artificial neural networks has shown that they are very well suited to represent models comparable in complexity to those required in this project.
  3. Integration of the ground interaction models into a simulation environment existing at DFKI as a digital twin - By integrating the models into a simulation environment, they can be evaluated based on the holistic robot behavior and compared with the behavior from the data acquisition of the real systems. The goal is an accurate real-time simulation that can be used for system design as well as path planning.
  4. Integration of ground interaction models into robot control to increase autonomy - by continuously matching robot performance with a prediction generated from a simulation running on the robot, the systems will be able to continuously determine soil conditions and detect deteriorating conditions at an early stage. The robot should react accordingly to changing soil conditions, for example by triggering new path planning or appropriate behavior adjustments.

Since the data-driven approach means that the soil interaction models have to be trained on a system-specific basis, it is not possible to generate a generally applicable model in NoStrandAMust, as is possible with analytical models. Nevertheless, in order to demonstrate the general applicability of the method, six different systems will be used in NoStrandAMust. These include three walking machines (Charlie, CREX, and Mantis), two wheel-driven systems with different concepts (SherpaTT, and Artemis), and a mixture between walking and wheel systems in the form of a so-called star wheel (Coyote III). In addition, the weight class of the systems ranges from about 20 kg to about 120 kg for both the running systems and the wheel concepts. Each of the six systems is tested on substrates with different properties. In addition to a distinction between loose sedimentary soils and hard subsoils, there will also be different variants within these two classes. It is envisaged here that the ''loose sediment'' class will include fine sand, fine gravel, coarse gravel or basalt split. For hard soils, the systems will be used to record data that have different friction coefficients, such as dust-covered surfaces or high friction as found in lava caves.


BMWK - Federal Ministry for Economic Affairs and Climate Action


BMWK - Federal Ministry for Economic Affairs and Climate Action

Publications about the project

Alexander Dettmann; Malte Langosz; Jonas Eisenmenger; Marc Otto; Sebastian Kasperski; Malte Wirkus; Nayari Lessa

In: 13th EASN International Conference on Innovation in Aviation & Space for opening New Horizons (13th EASN 2023). EASN International Conference on Innovation in Aviation and Space for opening New Horizons (EASN), September 5-8, Salerno, Italy, Journal of Physics: Conference Series (JPCS), IOP Publishing Ltd, 2024.

To the publication
